Investigating the effects of coastal stressors on the distribution of genomic variation of oyster populations in Narragansett Bay

Poster from Evolution 2019

Investigating how larval response to multiple coastal stressors shapes the distribution of genomic variation of adult oysters

Amy Zyck1, Rebecca Stevick2, Marta Gomez-Chiarri2, & Jonathan Puritz1

  1. University of Rhode Island, Department of Biological Sciences
  2. University of Rhode Island, Department of Fisheries, Animal, and Veterinary Sciences

Background (project description)

During the summer of 2017, exposure trials were conducted using larvae from the eastern oyster (Crassostrea virginica). Wild adult broodstock were collected from Ipswich, MA and Barnstable, MA, and brought into the lab and conditioned for several weeks. Oysters were spawned via thermal induction and eggs from 7 females were fertilized with sperm from 11 males. Larvae were kept in ambient, filtered sea water for 16 hours to ensure all embryos had developed to the trochophore larval stage. After 16 hours, larvae were counted and approximately ~125,000 larvae were transferred to twelve 1 L glass mesocosms and four replicate 100,000 larvae subsamples were flash frozen (T0). Ambient water was adjusted to 100 mL and larvae were allowed to acclimate for 1 hour. After acclimation, one of four treatments were randomly assigned to each mesocosm (4 per treatment): CON-Control conditions, CA- Coastal Acidification treatment of ~2800 µatm pCO2 seawater, SE- Sewage Effluent treatment of 5% volume to volume ratio of treated sewage effluent to sea water, CASE- Coastal Acidification and Sewage Effluent treatment of 5% volume to volume ratio of treated sewage effluent to sea water ~2800 µatm pCO2. At 24 hours post-exposure (T24), larvae were filtered out of their experimental bottles and flash frozen to preserve the DNA and RNA. RNA was extracted from all samples, mRNA libraries were prepared and normalized, and probes were synthesized (adapter removal and biotin labeling).

In 2017, adult oysters were collected from 4 sites in Narragansett Bay (Figure 1), with 10 individuals from each site. In 2020, 10 adult oysters were collected from each of 4 additional sites in Narragansett Bay and the Narrow River site was resampled to serve as a control across sampling years (Figure 2). Rectum, gill, and mantle tissue was dissected from each sample. DNA was then extracted from the tissue following the DNeasy Blood and Tissue extraction protocol and sheared down to 150 base pair fragments. Environmental data was also collected from each sample site by deployed data loggers or fixed site monitoring from other groups. The collected environmental data includes: temperature, salinity, pH, dissolved oxygen, and chlorophyll-a concentrations. We also calculated the potential influence of sewage effluent at each site by identifying wastewater treatment facilities in close proximity to each site (Figure 3) and determining the outflow from each facility.

The probes, generated from the larval oyster mRNA, were then hybridized with the adult oyster DNA to capture expressed exon regions. After washing away non-target DNA regions and eluting the captured DNA off of the beads, the DNA is sequenced, resulting in a direct capture of genomic sequences that correspond to expressed genes related to coastal stressor response in larval oysters (Puritz and Lotterhos 2018). The sequences obtained from this experiment and collected environmental data from Narragansett Bay will allow for the examination of allele frequencies at target (putatively under selection) loci in adult populations that are exposed to coastal stressors in their natural habitat.


  • Use sequence capture probes synthesized from CASE larval mRNA to capture expressed exon regions in adult oyster DNA related to coastal stressor response in larvae
  • Identify loci putatively under selection across these 4 populations
  • Analyze associations between environmental data in Narragansett Bay and putatively adaptive loci and neutral loci in adults to examine if selective or neutral proceesses may be shaping population structure in this system
  • Identify putatively adaptive loci in CASE larvae and examine associations with environmental data in Narragansett Bay to elucidate if selection at the larval stage is shaping the genomic variation of adult oysters
  • Identify putatively adaptive loci shared by both adult and larval oysters and associations with environmental data to examine shared selective regimes across life-history stages

Samples Sites

Table 1: The names, ID’s, and geographic locations (provided as latitude and longitude) of the 8 sample sites in Narragansett Bay, RI.

Station #Station nameStation IDSample YearLatitudeLongitudeAdd. Location Info
1ProvidencePVD201741.816-71.391Bold Point Park
2Greenwich BayGB201741.654-71.445Goddard Park Boat Launch
3Bissel CoveBIS201741.545-71.431Rome Point
4Narrow RiverNAR2017 & 202041.505-71.453River Road
5BarringtonBAR202041.741-71.305Barrington Public Library
6KickemuitKIC202041.698-71.247Narrows Fishing Area
7Mary C. Donovan MarshMCD202041.547-71.203Pond Bridge Road
8Green Hill PondGHP202041.374-71.620Beech Road Parking Area

Wastewater Treatment Plants

Table 2: The names, ID’s, and geographic locations (provided as latitude and longitude) of the wastewater treatment plants located in and around Narragansett Bay, RI.

Wastewater Treatment PlantIDLatitudeLongitude
Narragansett Bay Commission - Bucklin PointNBCB41.8514102-71.36403
Narragansett Bay Commission - Fields PointNBCF41.794747-71.391006
East Providence Wastewater Treatment FacilityEPW41.773839-71.364992
Warren Wastewater Treatment FacilityWAW41.726278–71.285239
Somerset Sewer Treatment PlantSST41.717475-71.168569
Brayton Point StationBPS41.661614-71.263894
Bristol Wastewater Treatment FacilityBrW41.661614-71.263894
Fall River Wastewater TreatmentFRW41.676875-71.191211
East Greenwich Bay WastewaterEGW41.658703-71.448131
Quonset Point WastewaterQPW41.588386-71.408497
Jamestown WastewaterJW41.509675-71.362322
Newport Wastewater Treatment FacilityNWTF41.512689-71.318022
South Kingstown WastewaterSKW41.425147-71.475606
Narragansett Wastewater Treatment FacilityNW41.384167-71.476736

Sampling Map


Figure 1: Adult oyster individuals were sampled from 4 different sites in Narragansett Bay, RI in 2017.


Figure 2: The 8 adult oysters sites sampled in Narragansett Bay, RI in 2017 and 2020.


Figure 3: Wastewater Treatment Facilities in Rhode Island and Massachusetts that have outflow into Narragansett Bay. Wastewater treatment facilities are blue, original four sample sites are red.


Puritz JB & KE Lotterhos (2018) Expressed exome capture sequencing: A method for cost-effective exome sequencing for all organisms. Mol. Ecol. Resour. 18(6):1209-1222. doi: 10.1111/1755-0998.12905.
